| 型号 |
反向击穿电压 （V） |
测试电流 | 可承受的反向电压 | 最大的反向漏电流 | 最大的浪涌电流 | 最大的钳位电压 | 封装形式 | ||
| Min | Max | It（mA） | Wwm（V） | ID（μA） | IPPM（A） | VC（V） | |||
| SMAJ5.0A |  |
6.4 | 7.3 | 10 | 5.0 | 800 | 41.6 | 9.6 | SMA |
| SMAJ5.0CA | |
6.4 | 7 | 10 | 5.0 | 800 | 43.5 | 9.2 | SMA |
| SMAJ6.0A | |
6.67 | 8.15 | 10 | 6.0 | 800 | 35.1 | 11.4 | SMA |
| SMAJ6.0CA | |
6.67 | 7.37 | 10 | 6.0 | 800 | 38.8 | 10.3 | SMA |
| SMAJ6.5A | |
7.22 | 8.82 | 10 | 6.5 | 500 | 32.5 | 12.3 | SMA |
| SMAJ6.5CA | |
7.22 | 7.98 | 10 | 6.5 | 500 | 35.7 | 11.2 | SMA |
| SMAJ7.0A | |
7.78 | 9.51 | 10 | 7.0 | 200 | 30.1 | 13.3 | SMA |
| SMAJ7.0CA | |
7.78 | 8.60 | 10 | 7.0 | 200 | 33.3 | 12.0 | SMA |
| SMAJ7.5A | |
8.33 | 10.3 | 1 | 7.5 | 100 | 28.0 | 14.3 | SMA |
| SMAJ7.5CA | |
8.33 | 8.21 | 1 | 7.5 | 100 | 31.0 | 12.9 | SMA |
| SMAJ8.0A | |
8.89 | 10.9 | 1 | 8.0 | 50 | 26.5 | 15.0 | SMA |
| SMAJ8.0CA | |
8.89 | 9.83 | 1 | 8.0 | 50 | 29.4 | 13.6 | SMA |
| SMAJ8.5A | |
9.44 | 11.5 | 1 | 8.5 | 10 | 25.1 | 15.9 | SMA |
| SMAJ8.5CA | |
9.44 | 10.4 | 1 | 8.5 | 10 | 27.7 | 14.4 | SMA |
| SMAJ9.0A | |
10.0 |
12.2 | 1 | 9.0 | 5 | 23.6 | 16.9 | SMA |
| SMAJ9.0CA | |
10.0 | 11.1 | 1 | 9.0 | 5 | 26.0 | 15.4 | SMA |
| SMAJ10A | |
11.1 | 13.6 | 1 | 10 | 5 | 21.1 | 18.8 | SMA |
| SMAJ10CA | |
11.1 | 12.3 | 1 | 10 | 5 | 23.5 | 17.0 | SMA |
| SMAJ11A | |
12.2 | 14.9 | 1 | 11 | 5 | 20.0 | 20.1 | SMA |
| SMAJ11CA | |
12.2 |
13.5 | 1 | 11 | 5 | 22.0 | 18.2 | SMA |
| SMAJ12A | |
13.3 | 16.3 | 1 | 12 | 5 | 18.1 | 22.0 | SMA |
| SMAJ12CA | |
13.3 | 14.7 | 1 | 12 | 5 | 20.1 | 19.9 | SMA |
| SMAJ13A | |
14.4 | 17.6 | 1 | 13 | 5 | 16.8 | 23.8 | SMA |
| SMAJ13CA | |
14.4 | 15.9 | 1 | 13 | 5 | 18.6 | 21.5 | SMA |
| SMAJ14A | |
15.6 |
19.1 | 1 | 14 | 5 | 15.5 | 25.8 | SMA |
| SMAJ14CA | |
15.6 | 17.2 | 1 | 14 | 5 | 17.2 | 23.2 | SMA |
| SMAJ15A | |
16.7 | 20.4 | 1 | 15 | 5 | 14.8 | 26.9 | SMA |
| SMAJ15CA | |
16.7 | 18.5 | 1 | 15 | 5 | 16.4 | 24.4 | SMA |
| SMAJ16A | |
17.8 | 21.8 | 1 | 16 | 5 | 13.8 | 28.8 | SMA |
| SMAJ16CA | |
17.8 | 19.7 | 1 | 16 | 5 | 15.3 | 26.0 | SMA |
| SMAJ17A | |
18.9 | 23.1 | 1 | 17 | 5 | 13.1 | 30.5 | SMA |
| SMAJ17CA | |
18.9 | 20.9 | 1 | 17 | 5 | 14.5 | 27.6 | SMA |
| SMAJ18A | |
20.0 | 24.4 | 1 | 18 | 5 | 12.4 | 32.2 | SMA |
| SMAJ18CA | |
20.0 | 22.1 | 1 | 18 | 5 | 13.7 | 29.2 | SMA |
| SMAJ20A | |
22.2 | 27.1 | 1 | 20 | 5 | 11.1 | 35.8 | SMA |
| SMAJ20CA | |
22.2 | 24.5 | 1 | 20 | 5 | 12.3 | 32.4 | SMA |
| SMAJ22A | |
24.4 | 29.8 | 1 | 22 | 5 | 10.1 | 39.4 | SMA |
| SMAJ22CA | |
24.4 | 26.9 | 1 | 22 | 5 | 11.2 | 35.5 | SMA |
| SMAJ24A | |
26.7 | 32.6 | 1 | 24 | 5 | 9.3 | 43.0 | SMA |
| SMAJ24CA | |
26.7 | 29.5 | 1 | 24 | 5 | 10.3 | 38.9 | SMA |
| SMAJ26A | |
28.9 | 35.3 | 1 | 26 | 5 | 8.6 | 46.6 | SMA |
| SMAJ26CA | |
28.9 | 31.9 | 1 | 26 | 5 | 9.5 | 42.1 | SMA |
| SMAJ28A | |
31.1 | 38.0 | 1 | 28 | 5 | 8.0 | 50.0 | SMA |
| SMAJ28CA | |
31.1 | 34.4 | 1 | 28 | 5 | 8.8 | 45.4 | SMA |
| SMAJ30A | |
33.3 | 40.7 | 1 | 30 | 5 | 7.5 | 53.5 | SMA |
| SMAJ30CA | |
33.3 | 36.8 | 1 | 30 | 5 | 8.3 | 48.4 | SMA |
| SMAJ33A | |
36.7 | 44.9 | 1 | 33 | 5 | 6.8 | 59.0 | SMA |
| SMAJ33CA | |
36.7 | 40.6 | 1 | 33 | 5 | 7.5 | 53.3 | SMA |
| SMAJ36A | |
40.0 | 48.9 | 1 | 36 | 5 | 6.2 | 64.3 | SMA |
| SMAJ36CA | |
40.0 | 44.2 | 1 | 36 | 5 | 6.9 | 58.1 | SMA |
| SMAJ40A | |
44.4 | 54.3 | 1 | 40 | 5 | 5.6 | 71.4 | SMA |
| SMAJ40CA | |
44.4 | 49.1 | 1 | 40 | 5 | 6.2 | 64.5 | SMA |
| SMAJ43A | |
47.8 | 58.4 | 1 | 43 | 5 | 5.2 | 76.7 | SMA |
| SMAJ43CA | |
47.8 | 52.8 | 1 | 43 | 5 | 5.7 | 69.4 | SMA |
| SMAJ45A | |
50.0 | 61.1 | 1 | 45 | 5 | 5.0 | 80.3 | SMA |
| SMAJ45CA | |
50.0 | 55.3 | 1 | 45 | 5 | 5.5 | 72.7 | SMA |
| SMAJ48A | |
53.3 | 65.1 | 1 | 48 | 5 | 4.7 | 85.5 | SMA |
| SMAJ48CA | |
53.3 | 58.9 | 1 | 48 | 5 | 5.2 | 77.4 | SMA |
| SMAJ51A | |
56.7 | 69.3 | 1 | 51 | 5 | 4.4 | 91.1 | SMA |
| SMAJ51CA | |
56.7 | 62.7 | 1 | 51 | 5 | 4.9 | 82.4 | SMA |
| SMAJ54A | |
60.0 | 73.3 | 1 | 54 | 5 | 4.2 | 96.3 | SMA |
| SMAJ54CA | |
60.0 | 66.3 | 1 | 54 | 5 | 4.6 | 87.1 | SMA |
| SMAJ58A | |
64.4 | 78.7 | 1 | 58 | 5 | 3.9 | 103 | SMA |
| SMAJ58CA | |
64.4 | 71.2 | 1 | 58 | 5 | 4.3 | 93.6 | SMA |
| SMAJ60A | |
66.7 | 81.5 | 1 | 60 | 5 | 3.7 | 107 | SMA |
| SMAJ60CA | |
66.7 | 73.7 | 1 | 60 | 5 | 4.1 | 96.8 | SMA |
| SMAJ64A | |
71.1 | 86.4 | 1 | 64 | 5 | 4.5 | 114 | SMA |
| SMAJ64CA | |
71.1 | 78.6 | 1 | 64 | 5 | 3.9 | 103 | SMA |
| SMAJ70A | |
77.8 | 95.1 | 1 | 70 | 5 | 3.2 | 125 | SMA |
| SMAJ70CA | |
78.8 | 86.0 | 1 | 70 | 5 | 3.5 | 113 | SMA |
| SMAJ75A | |
83.3 | 102 | 1 | 75 | 5 | 3.0 | 134 | SMA |
| SMAJ75CA | |
83.3 | 92.1 | 1 | 75 | 5 | 3.3 | 121 | SMA |
| SMAJ78A | |
86.7 | 106 | 1 | 78 | 5 | 2.9 | 139 | SMA |
| SMAJ78CA | |
86.7 | 95.8 | 1 | 78 | 5 | 3.2 | 126 | SMA |
| SMAJ85A | |
94.4 | 115 | 1 | 85 | 5 | 2.6 | 151 | SMA |
| SMAJ85CA | |
94.4 | 104 | 1 | 85 | 5 | 2.9 | 137 | SMA |
| SMAJ90A | |
100 | 122 | 1 | 90 | 5 | 2.5 | 160 | SMA |
| SMAJ90CA | |
100 | 111 | 1 | 90 | 5 | 2.7 | 146 | SMA |
| SMAJ100A | |
111 | 136 | 1 | 100 | 5 | 2.2 | 179 | SMA |
| SMAJ100CA | |
111 | 123 | 1 | 100 | 5 | 2.5 | 162 | SMA |
| SMAJ110A | |
122 | 149 | 1 | 110 | 5 | 2.0 | 196 | SMA |
| SMAJ110CA | |
122 | 135 | 1 | 110 | 5 | 2.3 | 177 | SMA |
| SMAJ120A | |
133 | 163 | 1 | 120 | 5 | 1.9 | 214 | SMA |
| SMAJ120CA | |
133 | 147 | 1 | 120 | 5 | 2.0 | 193 | SMA |
| SMAJ130A | |
144 | 176 | 1 | 130 | 5 | 1.7 | 231 | SMA |
| SMAJ130CA | |
144 | 159 | 1 | 130 | 5 | 1.9 | 209 | SMA |
| SMAJ150A | |
167 | 204 | 1 | 150 | 5 | 1.5 | 268 | SMA |
| SMAJ150CA | |
167 | 185 | 1 | 150 | 5 | 1.6 | 243 | SMA |
| SMAJ160A | |
178 | 218 | 1 | 160 | 5 | 1.4 | 287 | SMA |
| SMAJ160CA | |
178 | 197 | 1 | 160 | 5 | 1.5 | 259 | SMA |
| SMAJ170A | |
189 | 231 | 1 | 170 | 5 | 1.3 | 304 | SMA |
| SMAJ170CA | |
189 | 209 | 1 | 170 | 5 | 1.4 | 275 | SMA |
| SMBJ5.0A | |
6.4 | 7.82 | 10 | 5.0 | 800 | 62.5 | 9.6 | SMB |
| SMBJ5.0CA | |
6.4 | 7.07 | 10 | 5.0 | 800 | 65.2 | 9.2 | SMB |
| SMBJ6.0A | |
6.67 | 8.15 | 10 | 6.0 | 800 | 52.6 | 11.4 | SMB |
| SMBJ6.0CA | |
6.67 | 7.37 | 10 | 6.0 | 800 | 58.3 | 10.3 | SMB |
| SMBJ6.5A | |
7.22 | 8.82 | 10 | 6.5 | 500 | 48.8 | 12.3 | SMB |
| SMBJ6.5CA | |
7.22 | 7.98 | 10 | 6.5 | 500 | 53.6 | 11.2 | SMB |
| SMBJ7.0A | |
7.78 | 9.51 | 10 | 7.0 | 200 | 45.1 | 13.3 | SMB |
| SMBJ7.0CA | |
7.78 | 8.60 | 10 | 7.0 | 200 | 50.0 | 12.0 | SMB |
| SMBJ7.5A | |
8.33 | 10.2 | 1 | 7.5 | 100 | 42.0 | 14.3 | SMB |
| SMBJ7.5CA | |
8.33 | 9.21 | 1 | 7.5 | 100 | 46.5 | 12.9 | SMB |
| SMBJ8.0A | |
8.89 | 10.9 | 1 | 8.0 | 50 | 40.0 | 15.0 | SMB |
| SMBJ8.0CA | |
8.89 | 9.83 | 1 | 8.0 | 50 | 44.1 | 13.6 | SMB |
| SMBJ8.5A | |
9.44 | 11.5 | 1 | 8.5 | 20 | 37.7 | 15.9 | SMB |
| SMBJ8.5CA | |
9.44 | 10.4 | 1 | 8.5 | 20 | 41.7 | 14.4 | SMB |
| SMBJ9.0A | |
10.0 |
12.2 | 1 | 9.0 | 10 | 35.5 | 16.9 | SMB |
| SMBJ9.0CA | |
10.0 | 11.1 | 1 | 9.0 | 10 | 39.0 | 15.4 | SMB |
| SMBJ10A | |
11.1 | 13.6 | 1 | 10 | 5 | 31.9 | 18.8 | SMB |
| SMBJ10CA | |
11.1 | 12.3 | 1 | 10 | 5 | 35.3 | 17.0 | SMB |
| SMBJ11A | |
12.2 | 14.9 | 1 | 11 | 5 | 29.9 | 20.1 | SMB |
| SMBJ11CA | |
12.2 |
13.5 | 1 | 11 | 5 | 33 | 18.2 | SMB |
| SMBJ12A | |
13.3 | 16.3 | 1 | 12 | 5 | 27 | 22.0 | SMB |
| SMBJ12CA | |
13.3 | 14.7 | 1 | 12 | 5 | 30.2 | 19.9 | SMB |
| SMBJ13A | |
14.4 | 17.6 | 1 | 13 | 1 | 25.2 | 23.8 | SMB |
| SMBJ13CA | |
14.4 | 15.9 | 1 | 13 | 1 | 27.9 | 21.5 | SMB |
| SMBJ14A | |
15.6 |
19.1 | 1 | 14 | 1 | 23.3 | 25.8 | SMB |
| SMBJ14CA | |
15.6 | 17.2 | 1 | 14 | 1 | 25.9 | 23.2 | SMB |
| SMBJ15A | |
16.7 | 20.4 | 1 | 15 | 1 | 22.3 | 26.9 | SMB |
| SMBJ15CA | |
16.7 | 18.5 | 1 | 15 | 1 | 24.6 | 24.4 | SMB |
| SMBJ16A | |
17.8 | 21.8 | 1 | 16 | 1 | 20.8 | 28.8 | SMB |
| SMBJ16CA | |
17.8 | 19.7 | 1 | 16 | 1 | 23.1 | 26.0 | SMB |
| SMBJ17A | |
18.9 | 23.1 | 1 | 17 | 1 | 19.7 | 30.5 | SMB |
| SMBJ17CA | |
18.9 | 20.9 | 1 | 17 | 1 | 21.7 | 27.6 | SMB |
| SMBJ18A | |
20.0 | 24.4 | 1 | 18 | 1 | 18.6 | 32.2 | SMB |
| SMBJ18CA | |
20.0 | 22.1 | 1 | 18 | 1 | 20.5 | 29.2 | SMB |
| SMBJ20A | |
22.2 | 27.1 | 1 | 20 | 1 | 16.8 | 35.8 | SMB |
| SMBJ20CA | |
22.2 | 24.5 | 1 | 20 | 1 | 18.5 | 32.4 | SMB |
| SMBJ22A | |
24.4 | 29.8 | 1 | 22 | 1 | 15.2 | 39.4 | SMB |
| SMBJ22CA | |
24.4 | 26.9 | 1 | 22 | 1 | 16.9 | 35.5 | SMB |
| SMBJ24A | |
26.7 | 32.6 | 1 | 24 | 1 | 14.0 | 43.0 | SMB |
| SMBJ24CA | |
26.7 | 29.5 | 1 | 24 | 1 | 15.4 | 38.9 | SMB |
| SMBJ26A | |
28.9 | 35.3 | 1 | 26 | 1 | 12.9 | 46.6 | SMB |
| SMBJ26CA | |
28.9 | 31.9 | 1 | 26 | 1 | 14.2 | 42.1 | SMB |
| SMBJ28A | |
31.1 | 38.0 | 1 | 28 | 1 | 12.0 | 50.0 | SMB |
| SMBJ28CA | |
31.1 | 34.4 | 1 | 28 | 1 | 13.2 | 45.4 | SMB |
| SMBJ30A | |
33.3 | 40.7 | 1 | 30 | 1 | 11.2 | 53.5 | SMB |
| SMBJ30CA | |
33.3 | 36.8 | 1 | 30 | 1 | 12.4 | 48.4 | SMB |
| SMBJ33A | |
36.7 | 44.9 | 1 | 33 | 1 | 10.2 | 59.0 | SMB |
| SMBJ33CA | |
36.7 | 40.6 | 1 | 33 | 1 | 11.3 | 53.3 | SMB |
| SMBJ36A | |
40.0 | 48.9 | 1 | 36 | 1 | 9.3 | 64.3 | SMB |
| SMBJ36CA | |
40.0 | 44.2 | 1 | 36 | 1 | 10.3 | 58.1 | SMB |
| SMBJ40A | |
44.4 | 54.3 | 1 | 40 | 1 | 8.4 | 71.4 | SMB |
| SMBJ40CA | |
44.4 | 49.1 | 1 | 40 | 1 | 9.3 | 64.5 | SMB |
| SMBJ43A | |
47.8 | 58.4 | 1 | 43 | 1 | 7.8 | 76.7 | SMB |
| SMBJ43CA | |
47.8 | 52.8 | 1 | 43 | 1 | 8.6 | 69.4 | SMB |
| SMBJ45A | |
50.0 | 61.1 | 1 | 45 | 1 | 7.5 | 80.3 | SMB |
| SMBJ45CA | |
50.0 | 55.3 | 1 | 45 | 1 | 8.3 | 72.7 | SMB |
| SMBJ48A | |
53.3 | 65.1 | 1 | 48 | 1 | 7.0 | 85.5 | SMB |
| SMBJ48CA | |
53.3 | 58.9 | 1 | 48 | 1 | 7.8 | 77.4 | SMB |
| SMBJ51A | |
56.7 | 69.3 | 1 | 51 | 1 | 6.6 | 91.1 | SMB |
| SMBJ51CA | |
56.7 | 62.7 | 1 | 51 | 1 | 7.3 | 82.4 | SMB |
| SMBJ54A | |
60.0 | 73.3 | 1 | 54 | 1 | 6.2 | 96.3 | SMB |
| SMBJ54CA | |
60.0 | 66.3 | 1 | 54 | 1 | 6.9 | 87.1 | SMB |
| SMBJ58A | |
64.4 | 78.7 | 1 | 58 | 1 | 5.8 | 103 | SMB |
| SMBJ58CA | |
64.4 | 71.2 | 1 | 58 | 1 | 6.4 | 93.6 | SMB |
| SMBJ60A | |
66.7 | 81.5 | 1 | 60 | 1 | 5.6 | 107 | SMB |
| SMBJ60CA | |
66.7 | 73.7 | 1 | 60 | 1 | 6.2 | 96.8 | SMB |
| SMBJ64A | |
71.1 | 86.9 | 1 | 64 | 1 | 5.3 | 114 | SMB |
| SMBJ64CA | |
71.1 | 78.6 | 1 | 64 | 1 | 5.8 | 103 | SMB |
| SMBJ70A | |
77.8 | 95.1 | 1 | 70 | 1 | 4.8 | 125 | SMB |
| SMBJ70CA | |
78.8 | 86.0 | 1 | 70 | 1 | 5.3 | 113 | SMB |
| SMBJ75A | |
83.3 | 102 | 1 | 75 | 1 | 4.5 | 134 | SMB |
| SMBJ75CA | |
83.3 | 92.1 | 1 | 75 | 1 | 5.0 | 121 | SMB |
| SMBJ78A | |
86.7 | 106 | 1 | 78 | 1 | 4.3 | 139 | SMB |
| SMBJ78CA | |
86.7 | 95.8 | 1 | 78 | 1 | 4.8 | 126 | SMB |
| SMBJ85A | |
94.4 | 115 | 1 | 85 | 1 | 4.0 | 151 | SMB |
| SMBJ85CA | |
94.4 | 104 | 1 | 85 | 1 | 4.4 | 137 | SMB |
| SMBJ90A | |
100 | 122 | 1 | 90 | 1 | 3.8 | 160 | SMB |
| SMBJ90CA | |
100 | 111 | 1 | 90 | 1 | 4.1 | 146 | SMB |
| SMBJ100A | |
111 | 136 | 1 | 100 | 1 | 3.4 | 179 | SMB |
| SMBJ100CA | |
111 | 123 | 1 | 100 | 1 | 3.7 | 162 | SMB |
| SMBJ110A | |
122 | 149 | 1 | 110 | 1 | 3.1 | 196 | SMB |
| SMBJ110CA | |
122 | 135 | 1 | 110 | 1 | 3.4 | 177 | SMB |
| SMBJ120A | |
133 | 163 | 1 | 120 | 1 | 2.8 | 214 | SMB |
| SMBJ120CA | |
133 | 147 | 1 | 120 | 1 | 3.1 | 193 | SMB |
| SMBJ130A | |
144 | 176 | 1 | 130 | 1 | 2.6 | 231 | SMB |
| SMBJ130CA | |
144 | 159 | 1 | 130 | 1 | 2.9 | 209 | SMB |
| SMBJ150A | |
167 | 204 | 1 | 150 | 1 | 2.2 | 268 | SMB |
| SMBJ150CA | |
167 | 185 | 1 | 150 | 1 | 2.5 | 243 | SMB |
| SMBJ160A | |
178 | 218 | 1 | 160 | 1 | 2.1 | 287 | SMB |
| SMBJ160CA | |
178 | 197 | 1 | 160 | 1 | 2.3 | 259 | SMB |
| SMBJ170A | |
189 | 231 | 1 | 170 | 1 | 2.0 | 304 | SMB |
| SMBJ170CA | |
189 | 209 | 1 | 170 | 1 | 2.2 | 275 | SMB |
| SMBJ188A | |
209 | 255 | 1 | 188 | 1 | 1.7 | 344 | SMB |
| SMBJ188CA | |
209 | 231 | 1 | 188 | 1 | 2.0 | 328 | SMB |
| SMCJ5.0A | |
6.4 | 7.82 | 10 | 5.0 | 1000 | 156.3 | 9.6 | SMC |
| SMCJ5.0CA | |
6.4 | 7.07 | 10 | 5.0 | 1000 | 163.0 | 9.2 | SMC |
| SMCJ6.0A | |
6.67 | 8.15 | 10 | 6.0 | 1000 | 131.6 | 11.4 | SMC |
| SMCJ6.0CA | |
6.67 | 7.37 | 10 | 6.0 | 1000 | 145.6 | 10.3 | SMC |
| SMCJ6.5A | |
7.22 | 8.82 | 10 | 6.5 | 500 | 122.0 | 12.3 | SMC |
| SMCJ6.5CA | |
7.22 | 7.98 | 10 | 6.5 | 500 | 133.9 | 11.2 | SMC |
| SMCJ7.0A | |
7.78 | 9.51 | 10 | 7.0 | 200 | 112.8 | 13.3 | SMC |
| SMCJ7.0CA | |
7.78 | 8.60 | 10 | 7.0 | 200 | 125.0 | 12.0 | SMC |
| SMCJ7.5A | |
8.33 | 10.2 | 1 | 7.5 | 100 | 104.9 | 14.3 | SMC |
| SMCJ7.5CA | |
8.33 | 9.21 | 1 | 7.5 | 100 | 116.3 | 12.9 | SMC |
| SMCJ8.0A | |
8.89 | 10.9 | 1 | 8.0 | 50 | 100.0 | 15.0 | SMC |
| SMCJ8.0CA | |
8.89 | 9.83 | 1 | 8.0 | 50 | 110.3 | 13.6 | SMC |
| SMCJ8.5A | |
9.44 | 11.5 | 1 | 8.5 | 20 | 94.3 | 15.9 | SMC |
| SMCJ8.5CA | |
9.44 | 10.4 | 1 | 8.5 | 20 | 104.2 | 14.4 | SMC |
| SMCJ9.0A | |
10.0 |
12.2 | 1 | 9.0 | 10 | 88.8 | 16.9 | SMC |
| SMCJ9.0CA | |
10.0 | 11.1 | 1 | 9.0 | 10 | 97.4 | 15.4 | SMC |
| SMCJ10A | |
11.1 | 13.6 | 1 | 10 | 5 | 79.8 | 18.8 | SMC |
| SMCJ10CA | |
11.1 | 12.3 | 1 | 10 | 5 | 88.2 | 17.0 | SMC |
| SMCJ11A | |
12.2 | 14.9 | 1 | 11 | 5 | 74.6 | 20.1 | SMC |
| SMCJ11CA | |
12.2 |
13.5 | 1 | 11 | 5 | 82.4 | 18.2 | SMC |
| SMCJ12A | |
13.3 | 16.3 | 1 | 12 | 5 | 68.2 | 22.0 | SMC |
| SMCJ12CA | |
13.3 | 14.7 | 1 | 12 | 5 | 75.4 | 19.9 | SMC |
| SMCJ13A | |
14.4 | 17.6 | 1 | 13 | 1 | 63.0 | 23.8 | SMC |
| SMCJ13CA | |
14.4 | 15.9 | 1 | 13 | 1 | 69.8 | 21.5 | SMC |
| SMCJ14A | |
15.6 |
19.1 | 1 | 14 | 1 | 58.1 | 25.8 | SMC |
| SMCJ14CA | |
15.6 | 17.2 | 1 | 14 | 1 | 64.7 | 23.2 | SMC |
| SMCJ15A | |
16.7 | 20.4 | 1 | 15 | 1 | 55.8 | 26.9 | SMC |
| SMCJ15CA | |
16.7 | 18.5 | 1 | 15 | 1 | 61.5 | 24.4 | SMC |
| SMCJ16A | |
17.8 | 21.8 | 1 | 16 | 1 | 52.1 | 28.8 | SMC |
| SMCJ16CA | |
17.8 | 19.7 | 1 | 16 | 1 | 57.7 | 26.0 | SMC |
| SMCJ17A | |
18.9 | 23.1 | 1 | 17 | 1 | 49.2 | 30.5 | SMC |
| SMCJ17CA | |
18.9 | 20.9 | 1 | 17 | 1 | 54.3 | 27.6 | SMC |
| SMCJ18A | |
20.0 | 24.4 | 1 | 18 | 1 | 46.6 | 32.2 | SMC |
| SMCJ18CA | |
20.0 | 22.1 | 1 | 18 | 1 | 51.4 | 29.2 | SMC |
| SMCJ20A | |
22.2 | 27.1 | 1 | 20 | 1 | 41.9 | 35.8 | SMC |
| SMCJ20CA | |
22.2 | 24.5 | 1 | 20 | 1 | 46.3 | 32.4 | SMC |
| SMCJ22A | |
24.4 | 29.8 | 1 | 22 | 1 | 38.1 | 39.4 | SMC |
| SMCJ22CA | |
24.4 | 26.9 | 1 | 22 | 1 | 42.3 | 35.5 | SMC |
| SMCJ24A | |
26.7 | 32.6 | 1 | 24 | 1 | 34.9 | 43.0 | SMC |
| SMCJ24CA | |
26.7 | 29.5 | 1 | 24 | 1 | 38.6 | 38.9 | SMC |
| SMCJ26A | |
28.9 | 35.3 | 1 | 26 | 1 | 32.2 | 46.6 | SMC |
| SMCJ26CA | |
28.9 | 31.9 | 1 | 26 | 1 | 35.6 | 42.1 | SMC |
| SMCJ28A | |
31.1 | 38.0 | 1 | 28 | 1 | 30.0 | 50.0 | SMC |
| SMCJ28CA | |
31.1 | 34.4 | 1 | 28 | 1 | 33.0 | 45.4 | SMC |
| SMCJ30A | |
33.3 | 40.7 | 1 | 30 | 1 | 28.0 | 53.5 | SMC |
| SMCJ30CA | |
33.3 | 36.8 | 1 | 30 | 1 | 31.0 | 48.4 | SMC |
| SMCJ33A | |
36.7 | 44.9 | 1 | 33 | 1 | 25.4 | 59.0 | SMC |
| SMCJ33CA | |
36.7 | 40.6 | 1 | 33 | 1 | 28.1 | 53.3 | SMC |
| SMCJ36A | |
40.0 | 48.9 | 1 | 36 | 1 | 23.3 | 64.3 | SMC |
| SMCJ36CA | |
40.0 | 44.2 | 1 | 36 | 1 | 25.8 | 58.1 | SMC |
| SMCJ40A | |
44.4 | 54.3 | 1 | 40 | 1 | 21.0 | 71.4 | SMC |
| SMCJ40CA | |
44.4 | 49.1 | 1 | 40 | 1 | 23.3 | 64.5 | SMC |
| SMCJ43A | |
47.8 | 58.4 | 1 | 43 | 1 | 19.6 | 76.7 | SMC |
| SMCJ43CA | |
47.8 | 52.8 | 1 | 43 | 1 | 21.6 | 69.4 | SMC |
| SMCJ45A | |
50.0 | 61.1 | 1 | 45 | 1 | 18.7 | 80.3 | SMC |
| SMCJ45CA | |
50.0 | 55.3 | 1 | 45 | 1 | 20.6 | 72.7 | SMC |
| SMCJ48A | |
53.3 | 65.1 | 1 | 48 | 1 | 17.5 | 85.5 | SMC |
| SMCJ48CA | |
53.3 | 58.9 | 1 | 48 | 1 | 19.4 | 77.4 | SMC |
| SMCJ51A | |
56.7 | 69.3 | 1 | 51 | 1 | 16.5 | 91.1 | SMC |
| SMCJ51CA | |
56.7 | 62.7 | 1 | 51 | 1 | 18.2 | 82.4 | SMC |
| SMBJ54A | |
60.0 | 73.3 | 1 | 54 | 1 | 15.6 | 96.3 | SMC |
| SMCJ54CA | |
60.0 | 66.3 | 1 | 54 | 1 | 17.2 | 87.1 | SMC |
| SMCJ58A | |
64.4 | 78.7 | 1 | 58 | 1 | 14.6 | 103 | SMC |
| SMCJ58CA | |
64.4 | 71.2 | 1 | 58 | 1 | 16 | 93 | SMC |
| SMCJ60A | |
66.7 | 81.5 | 1 | 60 | 1 | 14 | 107 | SMC |
| SMCJ60CA | |
66.7 | 73.7 | 1 | 60 | 1 | 15.5 | 96.8 | SMC |
| SMCJ64A | |
71.1 | 86.9 | 1 | 64 | 1 | 13.2 | 114 | SMC |
| SMCJ64CA | |
71.1 | 78.6 | 1 | 64 | 1 | 14.6 | 103 | SMC |
| SMCJ70A | |
77.8 | 95.1 | 1 | 70 | 1 | 12.0 | 125 | SMC |
| SMCJ70CA | |
78.8 | 86.0 | 1 | 70 | 1 | 13.3 | 113 | SMC |
| SMCJ75A | |
83.3 | 102 | 1 | 75 | 1 | 11.2 | 134 | SMC |
| SMCJ75CA | |
83.3 | 92.1 | 1 | 75 | 1 | 12.4 | 121 | SMC |
| SMCJ78A | |
86.7 | 106 | 1 | 78 | 1 | 10.8 | 139 | SMC |
| SMCJ78CA | |
86.7 | 95.8 | 1 | 78 | 1 | 11.9 | 126 | SMC |
| SMCJ85A | |
94.4 | 115 | 1 | 85 | 1 | 9.9 | 151 | SMC |
| SMCJ85CA | |
94.4 | 104 | 1 | 85 | 1 | 10.9 | 137 | SMC |
| SMCJ90A | |
100 | 122 | 1 | 90 | 1 | 9.4 | 160 | SMC |
| SMCJ90CA | |
100 | 111 | 1 | 90 | 1 | 10.3 | 146 | SMC |
| SMCJ100A | |
111 | 136 | 1 | 100 | 1 | 8.4 | 179 | SMC |
| SMCJ100CA | |
111 | 123 | 1 | 100 | 1 | 9.3 | 162 | SMC |
| SMCJ110A | |
122 | 149 | 1 | 110 | 1 | 7.7 | 196 | SMC |
| SMCJ110CA | |
122 | 135 | 1 | 110 | 1 | 8.5 | 177 | SMC |
| SMCJ120A | |
133 | 163 | 1 | 120 | 1 | 7.0 | 214 | SMC |
| SMCJ120CA | |
133 | 147 | 1 | 120 | 1 | 7.8 | 193 | SMC |
| SMCJ130A | |
144 | 176 | 1 | 130 | 1 | 6.5 | 231 | SMC |
| SMCJ130CA | |
144 | 159 | 1 | 130 | 1 | 7.2 | 209 | SMC |
| SMCJ150A | |
167 | 204 | 1 | 150 | 1 | 5.6 | 268 | SMC |
| SMCJ150CA | |
167 | 185 | 1 | 150 | 1 | 6.2 | 243 | SMC |
| SMCJ160A | |
178 | 218 | 1 | 160 | 1 | 5.2 | 287 | SMC |
| SMCJ160CA | |
178 | 197 | 1 | 160 | 1 | 5.8 | 259 | SMC |
| SMCJ170A | |
189 | 231 | 1 | 170 | 1 | 4.9 | 304 | SMC |
| SMCJ170CA | |
189 | 209 | 1 | 170 | 1 | 5.5 | 275 | SMC |
| SMCJ188A | |
209 | 255 | 1 | 188 | 1 | 4.4 | 344 | SMC |
| SMCJ188CA | |
209 | 231 | 1 | 188 | 1 | 4.6 | 328 | SMC |
| 1.5SMC6.8A | |
6.45 | 7.14 | 10 | 5.8 | 1000 | 143 | 10.5 | SMC |
| 1.5SMC6.8CA | |
6.45 | 7.14 | 10 | 5.8 | 1000 | 143 | 10.5 | SMC |
| 1.5SMC7.5A | |
7.13 | 7.88 | 10 | 6.4 | 500 | 133 | 11.3 | SMC |
| 1.5SMC7.5CA | |
7.13 | 7.88 | 10 | 6.4 | 500 | 133 | 11.3 | SMC |
| 1.5SMC8.2A | |
7.79 | 8.61 | 10 | 7.02 | 200 | 124 | 12.1 | SMC |
| 1.5SMC8.2CA | |
7.79 | 8.61 | 10 | 7.02 | 200 | 124 | 12.1 | SMC |
| 1.5SMC9.1A | |
8.65 | 9.55 | 1 | 7.78 | 50 | 112 | 13.4 | SMC |
| 1.5SMC9.1CA | |
8.65 | 9.55 | 1 | 7.78 | 50 | 112 | 13.4 | SMC |
| 1.5SMC10A | |
9.50 | 10.5 | 1 | 8.55 | 10 | 103 | 14.5 | SMC |
| 1.5SMC10CA | |
9.50 | 10.5 | 1 | 8.55 | 10 | 103 | 14.5 | SMC |
| 1.5SMC11A | |
10.5 | 11.6 | 1 | 9.40 | 5 | 96.2 | 15.6 | SMC |
| 1.5SMC11CA | |
10.5 | 11.6 | 1 | 9.40 | 5 | 96.2 | 15.6 | SMC |
| 1.5SMC12A | |
11.4 | 12.6 | 1 | 10.2 | 5 | 89.8 | 16.7 | SMC |
| 1.5SMC12CA | |
11.4 | 12.6 | 1 | 10.2 | 5 | 89.8 | 16.7 | SMC |
| 1.5SMC13A | |
12.4 | 13.7 | 1 | 11.1 | 5 | 82.4 | 18.2 | SMC |
| 1.5SMC13CA | |
12.4 | 13.7 | 1 | 11.1 | 5 | 82.4 | 18.2 | SMC |
| 1.5SMC15A | |
14.3 | 15.8 | 1 | 12.8 | 1 | 70.8 | 21.2 | SMC |
| 1.5SMC15CA | |
14.3 | 15.8 | 1 | 12.8 | 1 | 70.8 | 21.2 | SMC |
| 1.5SMC16A | |
15.2 | 16.8 | 1 | 13.6 | 1 | 66.7 | 22.5 | SMC |
| 1.5SMC16CA | |
15.2 | 16.8 | 1 | 13.6 | 1 | 66.7 | 22.5 | SMC |
| 1.5SMC18A | |
17.1 | 18.9 | 1 | 15.3 | 1 | 59.5 | 25.2 | SMC |
| 1.5SMC18CA | |
17.1 | 18.9 | 1 | 15.3 | 1 | 59.5 | 25.2 | SMC |
| 1.5SMC20A | |
19.0 | 21.0 | 1 | 17.1 | 1 | 54.2 | 27.7 | SMC |
| 1.5SMC20CA | |
19.0 | 21.0 | 1 | 17.1 | 1 | 54.2 | 27.7 | SMC |
| 1.5SMC22A | |
20.9 | 23.1 | 1 | 18.8 | 1 | 49.0 | 30.6 | SMC |
| 1.5SMC22CA | |
20.9 | 23.1 | 1 | 18.8 | 1 | 49.0 | 30.6 | SMC |
| 1.5SMC24A | |
22.8 | 25.2 | 1 | 20.5 | 1 | 45.2 | 33.2 | SMC |
| 1.5SMC24CA | |
22.8 | 25.2 | 1 | 20.5 | 1 | 45.2 | 33.2 | SMC |
| 1.5SMC27A | |
25.7 | 28.4 | 1 | 23.1 | 1 | 40.0 | 37.5 | SMC |
| 1.5SMC27CA | |
25.7 | 28.4 | 1 | 23.1 | 1 | 40.0 | 37.5 | SMC |
| 1.5SMC30A | |
28.5 | 31.5 | 1 | 25.6 | 1 | 36.2 | 41.4 | SMC |
| 1.5SMC30CA | |
28.5 | 31.5 | 1 | 25.6 | 1 | 36.2 | 41.4 | SMC |
| 1.5SMC33A | |
31.4 | 34.7 | 1 | 28.2 | 1 | 32.8 | 45.7 | SMC |
| 1.5SMC33CA | |
31.4 | 34.7 | 1 | 28.2 | 1 | 32.8 | 45.7 | SMC |
| 1.5SMC36A | |
34.2 | 37.8 | 1 | 30.8 | 1 | 30.1 | 49.9 | SMC |
| 1.5SMC36CA | |
34.2 | 37.8 | 1 | 30.8 | 1 | 30.1 | 49.9 | SMC |
| 1.5SMC39A | |
37.1 | 41.0 | 1 | 33.3 | 1 | 27.8 | 53.9 | SMC |
| 1.5SMC39CA | |
37.1 | 41.0 | 1 | 33.3 | 1 | 27.8 | 53.9 | SMC |
| 1.5SMC43A | |
40.9 | 45.2 | 1 | 36.8 | 1 | 25.3 | 59.3 | SMC |
| 1.5SMC43CA | |
40.9 | 45.2 | 1 | 36.8 | 1 | 25.3 | 59.3 | SMC |
| 1.5SMC47A | |
44.7 | 49.4 | 1 | 40.2 | 1 | 23.1 | 64.8 | SMC |
| 1.5SMC47CA | |
44.7 | 49.4 | 1 | 40.2 | 1 | 23.1 | 64.8 | SMC |
| 1.5SMC51A | |
48.5 | 53.6 | 1 | 43.6 | 1 | 21.4 | 70.1 | SMC |
| 1.5SMC51CA | |
48.5 | 53.6 | 1 | 43.6 | 1 | 21.4 | 70.1 | SMC |
| 1.5SMC56A | |
53.2 | 58.8 | 1 | 47.8 | 1 | 19.5 | 77.0 | SMC |
| 1.5SMC56CA | |
53.2 | 58.8 | 1 | 47.8 | 1 | 19.5 | 77.0 | SMC |
| 1.5SMC62A | |
58.9 | 65.1 | 1 | 53.0 | 1 | 17.6 | 85.0 | SMC |
| 1.5SMC62CA | |
58.9 | 65.1 | 1 | 53.0 | 1 | 17.6 | 85.0 | SMC |
| 1.5SMC68A | |
64.6 | 71.4 | 1 | 58.1 | 1 | 16.3 | 92.0 | SMC |
| 1.5SMC68CA | |
64.6 | 71.4 | 1 | 58.1 | 1 | 16.3 | 92.0 | SMC |
| 1.5SMC75A | |
71.3 | 78.8 | 1 | 64.1 | 1 | 14.6 | 104 | SMC |
| 1.5SMC75CA | |
71.3 | 78.8 | 1 | 64.1 | 1 | 14.6 | 104 | SMC |
| 1.5SMC82A | |
77.9 | 86.1 | 1 | 70.1 | 1 | 13.3 | 113 | SMC |
| 1.5SMC82CA | |
77.9 | 86.1 | 1 | 70.1 | 1 | 13.3 | 113 | SMC |
| 1.5SMC91A | |
86.5 | 95.5 | 1 | 77.8 | 1 | 12.0 | 125 | SMC |
| 1.5SMC91CA | |
86.5 | 95.5 | 1 | 77.8 | 1 | 12.0 | 125 | SMC |
| 1.5SMC100A | |
95.0 | 105 | 1 | 85.5 | 1 | 10.9 | 137 | SMC |
| 1.5SMC100CA | |
95.0 | 105 | 1 | 85.5 | 1 | 10.9 | 137 | SMC |
| 1.5SMC110A | |
105 | 116 | 1 | 94.0 | 1 | 9.9 | 152 | SMC |
| 1.5SMC110CA | |
105 | 116 | 1 | 94.0 | 1 | 9.9 | 152 | SMC |
| 1.5SMC120A | |
114 | 126 | 1 | 102 | 1 | 9.1 | 165 | SMC |
| 1.5SMC120CA | |
114 | 126 | 1 | 102 | 1 | 9.1 | 165 | SMC |
| 1.5SMC130A | |
124 | 137 | 1 | 111 | 1 | 8.4 | 179 | SMC |
| 1.5SMC130CA | |
124 | 137 | 1 | 111 | 1 | 8.4 | 179 | SMC |
| 1.5SMC150A | |
143 | 158 | 1 | 128 | 1 | 7.2 | 207 | SMC |
| 1.5SMC150CA | |
143 | 158 | 1 | 128 | 1 | 7.2 | 207 | SMC |
| 1.5SMC160A | |
152 | 168 | 1 | 136 | 1 | 6.8 | 219 | SMC |
| 1.5SMC160CA | |
152 | 168 | 1 | 136 | 1 | 6.8 | 219 | SMC |
| 1.5SMC170A | |
162 | 179 | 1 | 145 | 1 | 6.4 | 234 | SMC |
| 1.5SMC170CA | |
162 | 179 | 1 | 145 | 1 | 6.4 | 234 | SMC |
| 1.5SMC180A | |
171 | 189 | 1 | 154 | 1 | 6.1 | 246 | SMC |
| 1.5SMC180CA | |
171 | 189 | 1 | 154 | 1 | 6.1 | 246 | SMC |
| 1.5SMC200A | |
190 | 210 | 1 | 171 | 1 | 5.5 | 274 | SMC |
| 1.5SMC200CA | |
190 | 210 | 1 | 171 | 1 | 5.5 | 274 | SMC |
| 1.5SMC220A | |
209 | 231 | 1 | 185 | 1 | 4.6 | 328 | SMC |
| 1.5SMC220CA | |
209 | 231 | 1 | 185 | 1 | 4.6 | 328 | SMC |
| 1.5SMC250A | |
237 | 263 | 1 | 214 | 1 | 4.4 | 344 | SMC |
| 1.5SMC250CA | |
237 | 263 | 1 | 214 | 1 | 4.4 | 344 | SMC |
| 1.5SMC300A | |
285 | 315 | 1 | 256 | 1 | 3.6 | 414 | SMC |
| 1.5SMC300CA | |
285 | 315 | 1 | 256 | 1 | 3.6 | 414 | SMC |
| 1.5SMC350A | |
333 | 368 | 1 | 300 | 1 | 3.1 | 482 | SMC |
| 1.5SMC350CA | |
333 | 368 | 1 | 300 | 1 | 3.1 | 482 | SMC |
| 1.5SMC400A | |
380 | 420 | 1 | 342 | 1 | 2.7 | 548 | SMC |
| 1.5SMC400CA | |
380 | 420 | 1 | 342 | 1 | 2.7 | 548 | SMC |
| 1.5SMC440A | |
418 | 462 | 1 | 376 | 1 | 2.5 | 602 | SMC |
| 1.5SMC440CA | |
418 | 462 | 1 | 376 | 1 | 2.5 | 602 | SMC |
| 1.5SMC480A | |
456 | 504 | 1 | 408 | 1 | 2.28 | 658 | SMC |
| 1.5SMC480CA | |
456 | 504 | 1 | 408 | 1 | 2.28 | 658 | SMC |
| 1.5SMC510A | |
485 | 535 | 1 | 434 | 1 | 2.15 | 698 | SMC |
| 1.5SMC510CA | |
485 | 535 | 1 | 434 | 1 | 2.15 | 698 | SMC |
| 1.5SMC540A | |
513 | 567 | 1 | 459 | 1 | 2.03 | 740 | SMC |
| 1.5SMC540CA | |
513 | 567 | 1 | 459 | 1 | 2.03 | 740 | SMC |
| SMF5V0A | |
6.40 | 10 | 5 | 5 | 21.7 | 9.2 | SDO-123 | |
| SMF5V0CA | |
6.40 | 10 | 5 | 5 | 21.7 | 9.2 | SDO-123 | |
| SMF6V0A | |
6.67 | 10 | 6 | 26 | 19.4 | 10.3 | SDO-123 | |
| SMF6V0CA | |
6.67 | 10 | 6 | 26 | 19.4 | 10.3 | SDO-123 | |
| SMF6V5A | |
7.22 | 10 | 6.5 | 3 | 17.9 | 11.2 | SDO-123 | |
| SMF6V5CA | |
7.22 | 10 | 6.5 | 3 | 17.9 | 11.2 | SDO-123 | |
| SMF7V0A | |
7.78 | 10 | 7 | 0.1 | 16.7 | 12 | SDO-123 | |
| SMF7V0CA | |
7.78 | 10 | 7 | 0.1 | 16.7 | 12 | SDO-123 | |
| SMF7V5A | |
8.33 | 1 | 7.5 | 0.1 | 15.5 | 12.9 | SDO-123 | |
| SMF7V5CA | |
8.33 | 1 | 7.5 | 0.1 | 15.5 | 12.9 | SDO-123 | |
| SMF8V0A | |
8.89 | 1 | 8 | 0.1 | 14.7 | 13.6 | SDO-123 | |
| SMF8V0CA | |
8.89 | 1 | 8 | 0.1 | 14.7 | 13.6 | SDO-123 | |
| SMF8V5A | |
9.44 | 1 | 8.5 | 0.1 | 13.9 | 14.4 | SDO-123 | |
| SMF8V5CA | |
9.44 | 1 | 8.5 | 0.1 | 13.9 | 14.4 | SDO-123 | |
| SMF9V0A | |
10 | 1 | 9 | 0.1 | 13.5 | 15.4 | SDO-123 | |
| SMF9V0CA | |
10 | 1 | 9 | 0.1 | 13.5 | 15.4 | SDO-123 | |
| SMF10A | |
11.1 | 1 | 10 | 0.1 | 11.8 | 17 | SDO-123 | |
| SMF10CA | |
11.1 | 1 | 10 | 0.1 | 11.8 | 17 | SDO-123 | |
| SMF11A | |
12.2 | 1 | 11 | 0.1 | 11 | 18.2 | SDO-123 | |
| SMF11CA | |
12.2 | 1 | 11 | 0.1 | 11 | 18.2 | SDO-123 | |
| SMF12A | |
13.3 | 1 | 12 | 0.1 | 10.1 | 19.9 | SDO-123 | |
| SMF12CA | |
13.3 | 1 | 12 | 0.1 | 10.1 | 19.9 | SDO-123 | |
| SMF13A | |
14.4 | 1 | 13 | 0.1 | 9.3 | 21.5 | SDO-123 | |
| SMF13CA | |
14.4 | 1 | 13 | 0.1 | 9.3 | 21.5 | SDO-123 | |
| SMF14A | |
15.6 | 1 | 14 | 0.1 | 8.6 | 23.2 | SDO-123 | |
| SMF14CA | |
15.6 | 1 | 14 | 0.1 | 8.6 | 23.2 | SDO-123 | |
| SMF15A | |
16.7 | 1 | 15 | 0.1 | 8.2 | 24.4 | SDO-123 | |
| SMF15CA | |
16.7 | 1 | 15 | 0.1 | 8.2 | 24.4 | SDO-123 | |
| SMF16A | |
17.8 | 1 | 16 | 0.1 | 7.7 | 26 | SDO-123 | |
| SMF16CA | |
17.8 | 1 | 16 | 0.1 | 7.7 | 26 | SDO-123 | |
| SMF17A | |
18.9 | 1 | 17 | 0.1 | 7.2 | 27.6 | SDO-123 | |
| SMF17CA | |
18.9 | 1 | 17 | 0.1 | 7.2 | 27.6 | SDO-123 | |
| SMF18A | |
20 | 1 | 18 | 0.1 | 6.8 | 29.2 | SDO-123 | |
| SMF18CA | |
20 | 1 | 18 | 0.1 | 6.8 | 29.2 | SDO-123 | |
| SMF20A | |
22.2 | 1 | 20 | 0.1 | 6.2 | 32.4 | SDO-123 | |
| SMF20CA | |
22.2 | 1 | 20 | 0.1 | 6.2 | 32.4 | SDO-123 | |
| SMF22A | |
24.4 | 1 | 22 | 0.1 | 5.6 | 35.5 | SDO-123 | |
| SMF22CA | |
24.4 | 1 | 22 | 0.1 | 5.6 | 35.5 | SDO-123 | |
| SMF24A | |
26.7 | 1 | 24 | 0.1 | 5.1 | 38.9 | SDO-123 | |
| SMF24CA | |
26.7 | 1 | 24 | 0.1 | 5.1 | 38.9 | SDO-123 | |
| SMF26A | |
28.9 | 1 | 26 | 0.1 | 4.8 | 42.1 | SDO-123 | |
| SMF26CA | |
28.9 | 1 | 26 | 0.1 | 4.8 | 42.1 | SDO-123 | |
| SMF28A | |
31.1 | 1 | 28 | 0.1 | 4.4 | 45.4 | SDO-123 | |
| SMF28CA | |
31.1 | 1 | 28 | 0.1 | 4.4 | 45.4 | SDO-123 | |
| SMF30A | |
33.3 | 1 | 30 | 0.1 | 4.1 | 48.4 | SDO-123 | |
| SMF30CA | |
33.3 | 1 | 30 | 0.1 | 4.1 | 48.4 | SDO-123 | |
| SMF33A | |
36.7 | 1 | 33 | 0.1 | 3.8 | 53.3 | SDO-123 | |
| SMF33CA | |
36.7 | 1 | 33 | 0.1 | 3.8 | 53.3 | SDO-123 | |
| SMF36A | |
40 | 1 | 36 | 0.1 | 3.4 | 58.1 | SDO-123 | |
| SMF36CA | |
40 | 1 | 36 | 0.1 | 3.4 | 58.1 | SDO-123 | |
| SMF40A | |
44.4 | 1 | 40 | 0.1 | 3.1 | 64.5 | SDO-123 | |
| SMF40CA | |
44.4 | 1 | 40 | 0.1 | 3.1 | 64.5 | SDO-123 | |
| SMF43A | |
47.8 | 1 | 43 | 0.1 | 2.9 | 69.4 | SDO-123 | |
| SMF43CA | |
47.8 | 1 | 43 | 0.1 | 2.9 | 69.4 | SDO-123 | |
| SMF45A | |
50 | 1 | 45 | 0.1 | 2.8 | 72.7 | SDO-123 | |
| SMF45CA | |
50 | 1 | 45 | 0.1 | 2.8 | 72.7 | SDO-123 | |
| SMF48A | |
53.3 | 1 | 48 | 0.1 | 2.6 | 77.4 | SDO-123 | |
| SMF48CA | |
53.3 | 1 | 48 | 0.1 | 2.6 | 77.4 | SDO-123 | |
| SMF51A | |
56.7 | 1 | 51 | 0.1 | 2.4 | 82.4 | SDO-123 | |
| SMF51CA | |
56.7 | 1 | 51 | 0.1 | 2.4 | 82.4 | SDO-123 | |
| SMF54A | |
60 | 1 | 54 | 0.1 | 2.25 | 88 | SDO-123 | |
| SMF54CA | |
60 | 1 | 54 | 0.1 | 2.25 | 88 | SDO-123 | |
| SMF58A | |
64.4 | 1 | 58 | 0.1 | 2.1 | 95 | SDO-123 | |
| SMF58CA | |
64.4 | 1 | 58 | 0.1 | 2.1 | 95 | SDO-123 | |
| P6SMB6.8A | |
6.45 | 7.14 | 10 | 5.8 | 1000 | 57.1 | 10.5 | SMB |
| P6SMB7.5A | |
7.13 | 7.88 | 10 | 6.4 | 500 | 53.1 | 11.3 | SMB |
| P6SMB8.2A | |
7.79 | 8.61 | 10 | 7.02 | 200 | 49.6 | 12.1 | SMB |
| P6SMB9.1A | |
8.65 | 9.55 | 1 | 7.78 | 50 | 44.8 | 13.4 | SMB |
| P6SMB10A | |
9.50 | 10.5 | 1 | 8.55 | 10 | 41.4 | 14.5 | SMB |
| P6SMB11A | |
10.5 | 11.6 | 1 | 9.40 | 5 | 38.5 | 15.6 | SMB |
| P6SMB12A | |
11.4 | 12.6 | 1 | 10.2 | 5 | 35.9 | 16.7 | SMB |
| P6SMB13A | |
12.4 | 13.7 | 1 | 11.1 | 5 | 33 | 18.2 | SMB |
| P6SMB15A | |
14.3 | 15.8 | 1 | 12.8 | 1 | 28.3 | 21.2 | SMB |
| P6SMB16A | |
15.2 | 16.8 | 1 | 13.6 | 1 | 26.7 | 22.5 | SMB |
| P6SMB18A | |
17.1 | 18.9 | 1 | 15.3 | 1 | 23.8 | 25.2 | SMB |
| P6SMB20A | |
19 | 21 | 1 | 17.12 | 1 | 21.7 | 27.7 | SMB |
| P6SMB22A | |
20.9 | 23.1 | 1 | 18.8 | 1 | 19.6 | 30.6 | SMB |
| P6SMB24A | |
22.8 | 25.2 | 1 | 20.5 | 1 | 18.1 | 33.2 | SMB |
| P6SMB27A | |
25.7 | 28.4 | 1 | 23.1 | 1 | 16 | 37.5 | SMB |
| P6SMB30A | |
28.5 | 31.5 | 1 | 25.6 | 1 | 14.5 | 41.4 | SMB |
| P6SMB33A | |
31.4 | 34.7 | 1 | 28.2 | 1 | 13.1 | 45.7 | SMB |
| P6SMB36A | |
34.2 | 37.8 | 1 | 30.8 | 1 | 12 | 49.9 | SMB |
| P6SMB39A | |
37.1 | 41 | 1 | 33.3 | 1 | 11.1 | 53.9 | SMB |
| P6SMB43A | |
40.9 | 45.2 | 1 | 36.8 | 1 | 10.1 | 59.3 | SMB |
| P6SMB47A | |
44.7 | 49.4 | 1 | 40.2 | 1 | 9.3 | 64.8 | SMB |
| P6SMB51A | |
48.5 | 53.6 | 1 | 43.6 | 1 | 8.6 | 70.1 | SMB |
| P6SMB56A | |
53.2 | 58.8 | 1 | 47.8 | 1 | 7.8 | 77 | SMB |
| P6SMB62A | |
58.9 | 65.1 | 1 | 53 | 1 | 7.1 | 85 | SMB |
| P6SMB68A | |
64.6 | 71.4 | 1 | 58.1 | 1 | 6.5 | 92 | SMB |
| P6SMB75A | |
71.3 | 78.8 | 1 | 64.1 | 1 | 5.8 | 103 | SMB |
| P6SMB82A | |
77.9 |
86.1 |
1 | 70.1 | 1 | 5.3 | 113 | SMB |
| P6SMB91A | |
86.5 | 95.5 | 1 | 77.8 | 1 | 4.8 | 125 | SMB |
| P6SMB100A | |
95 | 105 | 1 | 85.5 | 1 | 4.4 | 137 | SMB |
| P6SMB110A | |
105 | 116 | 1 | 94 | 1 | 3.9 | 152 | SMB |
| P6SMB120A | |
114 | 126 | 1 | 102 | 1 | 3.6 | 165 | SMB |
| P6SMB130A | |
124 | 137 | 1 | 111 | 1 | 3.4 | 179 | SMB |
| P6SMB150A | |
143 | 158 | 1 | 128 | 1 | 2.9 | 207 | SMB |
| P6SMB160A | |
152 | 168 | 1 | 136 | 1 | 2.7 | 219 | SMB |
| P6SMB170A | |
162 | 179 | 1 | 145 | 1 | 2.6 | 234 | SMB |
| P6SMB180A | |
171 | 189 | 1 | 154 | 1 | 2.4 | 246 | SMB |
| P6SMB200A | |
190 | 210 | 1 | 171 | 1 | 2.2 | 274 | SMB |
| P6SMB220A | |
209 | 231 | 1 | 185 | 1 | 1.8 | 328 | SMB |
| P6SMB250A | |
237 | 263 | 1 | 214 | 1 | 1.74 | 344 | SMB |
| P6SMB300A | |
285 | 315 | 1 | 256 | 1 | 1.45 | 414 | SMB |
| P6SMB350A | |
333 | 368 | 1 | 300 | 1 | 1.24 | 482 | SMB |
| P6SMB400A | |
380 | 420 | 1 | 342 | 1 | 1.1 | 548 | SMB |
| P6SMB440A | |
418 | 462 | 1 | 376 | 1 | 1 | 602 | SMB |
| P6SMB480A | |
456 | 504 | 1 | 408 | 1 | 0.91 | 658 | SMB |
| P6SMB510A | |
485 | 535 | 1 | 434 | 1 | 0.86 | 698 | SMB |
| P6SMB540A | |
513 | 567 | 1 | 459 | 1 | 0.81 | 740 | SMB |
| P6SMB6.8CA | |
6.45 | 7.14 | 10 | 5.8 | 1000 | 57.1 | 10.5 | SMB |
| P6SMB7.5CA | |
7.13 | 7.88 | 10 | 6.4 | 500 | 53.1 | 11.3 | SMB |
| P6SMB8.2CA | |
7.79 | 8.61 | 10 | 7.02 | 200 | 49.6 | 12.1 | SMB |
| P6SMB9.1CA | |
8.65 | 9.55 | 1 | 7.78 | 50 | 44.8 | 13.4 | SMB |
| P6SMB10CA | |
9.50 | 10.5 | 1 | 8.55 | 10 | 41.4 | 14.5 | SMB |
| P6SMB11CA | |
10.5 | 11.6 | 1 | 9.40 | 5 | 38.5 | 15.6 | SMB |
| P6SMB12CA | |
11.4 | 12.6 | 1 | 10.2 | 5 | 35.9 | 16.7 | SMB |
| P6SMB13CA | |
12.4 | 13.7 | 1 | 11.1 | 5 | 33 | 18.2 | SMB |
| P6SMB15CA | |
14.3 | 15.8 | 1 | 12.8 | 1 | 28.3 | 21.2 | SMB |
| P6SMB16CA | |
15.2 | 16.8 | 1 | 13.6 | 1 | 26.7 | 22.5 | SMB |
| P6SMB18CA | |
17.1 | 18.9 | 1 | 15.3 | 1 | 23.8 | 25.2 | SMB |
| P6SMB20CA | |
19 | 21 | 1 | 17.12 | 1 | 21.7 | 27.7 | SMB |
| P6SMB22CA | |
20.9 | 23.1 | 1 | 18.8 | 1 | 19.6 | 30.6 | SMB |
| P6SMB24CA | |
22.8 | 25.2 | 1 | 20.5 | 1 | 18.1 | 33.2 | SMB |
| P6SMB27CA | |
25.7 | 28.4 | 1 | 23.1 | 1 | 16 | 37.5 | SMB |
| P6SMB30CA | |
28.5 | 31.5 | 1 | 25.6 | 1 | 14.5 | 41.4 | SMB |
| P6SMB33CA | |
31.4 | 34.7 | 1 | 28.2 | 1 | 13.1 | 45.7 | SMB |
| P6SMB36CA | |
34.2 | 37.8 | 1 | 30.8 | 1 | 12 | 49.9 | SMB |
| P6SMB39CA | |
37.1 | 41 | 1 | 33.3 | 1 | 11.1 | 53.9 | SMB |
| P6SMB43CA | |
40.9 | 45.2 | 1 | 36.8 | 1 | 10.1 | 59.3 | SMB |
| P6SMB47CA | |
44.7 | 49.4 | 1 | 40.2 | 1 | 9.3 | 64.8 | SMB |
| P6SMB51CA | |
48.5 | 53.6 | 1 | 43.6 | 1 | 8.6 | 70.1 | SMB |
| P6SMB56CA | |
53.2 | 58.8 | 1 | 47.8 | 1 | 7.8 | 77 | SMB |
| P6SMB62CA | |
58.9 | 65.1 | 1 | 53 | 1 | 7.1 | 85 | SMB |
| P6SMB68CA | |
64.6 | 71.4 | 1 | 58.1 | 1 | 6.5 | 92 | SMB |
| P6SMB75CA | |
71.3 | 78.8 | 1 | 64.1 | 1 | 5.8 | 103 | SMB |
| P6SMB82CA | |
77.9 |
86.1 |
1 | 70.1 | 1 | 5.3 | 113 | SMB |
| P6SMB91CA | |
86.5 | 95.5 | 1 | 77.8 | 1 | 4.8 | 125 | SMB |
| P6SMB100CA | |
95 | 105 | 1 | 85.5 | 1 | 4.4 | 137 | SMB |
| P6SMB110CA | |
105 | 116 | 1 | 94 | 1 | 3.9 | 152 | SMB |
| P6SMB120CA | |
114 | 126 | 1 | 102 | 1 | 3.6 | 165 | SMB |
| P6SMB130CA | |
124 | 137 | 1 | 111 | 1 | 3.4 | 179 | SMB |
| P6SMB150CA | |
143 | 158 | 1 | 128 | 1 | 2.9 | 207 | SMB |
| P6SMB160CA | |
152 | 168 | 1 | 136 | 1 | 2.7 | 219 | SMB |
| P6SMB170CA | |
162 | 179 | 1 | 145 | 1 | 2.6 | 234 | SMB |
| P6SMB180CA | |
171 | 189 | 1 | 154 | 1 | 2.4 | 246 | SMB |
| P6SMB200CA | |
190 | 210 | 1 | 171 | 1 | 2.2 | 274 | SMB |
| P6SMB220CA | |
209 | 231 | 1 | 185 | 1 | 1.8 | 328 | SMB |
| P4SMA6.8A | |
6.12 | 7.48 | 10 | 5.5 | 1000 | 38 | 10.8 | SMA |
| P4SMA6.8CA | |
6.45 | 7.14 | 10 | 5.8 | 1000 | 40 | 10.5 | SMA |
| P4SMA7.5A | |
6.75 | 8.25 | 10 | 6.05 | 500 | 36 | 11.7 | SMA |
| P4SMA7.5CA | |
7.13 | 7.88 | 10 | 6.4 | 500 | 37 | 11.3 | SMA |
| P4SMA8.2A | |
7.38 | 9.02 | 10 | 6.63 | 200 | 33 | 12.5 | SMA |
| P4SMA8.2CA | |
7.79 | 8.61 | 10 | 7.02 | 200 | 35 | 12.1 | SMA |
| P4SMA9.1A | |
8.19 | 10 | 1 | 7.37 | 50 | 30 | 13.8 | SMA |
| P4SMA9.1CA | |
8.65 | 9.5 | 1 | 7.78 | 50 | 31 | 13.4 | SMA |
| P4SMA10A | |
9 | 11 | 1 | 8.1 | 10 | 28 | 15 | SMA |
| P4SMA10CA | |
9.5 | 10.5 | 1 | 8.55 | 10 | 29 | 14.5 | SMA |
| P4SMA11A | |
9.9 | 12.1 | 1 | 8.92 | 5 | 26 | 16.2 | SMA |
| P4SMA11CA | |
10.5 | 11.6 | 1 | 9.4 | 5 | 27 | 15.6 | SMA |
| P4SMA12A | |
10.8 | 13.2 | 1 | 9.72 | 5 | 24 | 17.3 | SMA |
| P4SMA12CA | |
11.4 | 12.6 | 1 | 10.2 | 5 | 25 | 16.7 | SMA |
| P4SMA13A | |
11.7 | 14.3 | 1 | 10.5 | 5 | 22 | 19 | SMA |
| P4SMA13CA | |
12.4 | 13.7 | 1 | 11.1 | 5 | 23 | 18.2 | SMA |
| P4SMA15A | |
13.5 | 16.5 | 1 | 12.1 | 5 | 19 | 22 | SMA |
| P4SMA15CA | |
14.3 | 15.8 | 1 | 12.8 | 5 | 20 | 21.2 | SMA |
| P4SMA16A | |
14.4 | 17.6 | 1 | 12.9 | 5 | 18 | 23.5 | SMA |
| P4SMA16CA | |
15.2 | 16.8 | 1 | 13.6 | 5 | 19 | 22.5 | SMA |
| P4SMA18A | |
16.2 | 19.8 | 1 | 14.5 | 5 | 16 | 26.5 | SMA |
| P4SMA18CA | |
17.1 | 18.9 | 1 | 15.3 | 5 | 17 | 25.2 | SMA |
| P4SMA20A | |
18 | 22 | 1 | 16.2 | 5 | 14 | 29.1 | SMA |
| P4SMA20CA | |
19 | 21 | 1 | 17.1 | 5 | 15 | 27.7 | SMA |
| P4SMA22A | |
19.8 | 24.2 | 1 | 17.8 | 5 | 13 | 31.9 | SMA |
| P4SMA22CA | |
20.9 | 23.1 | 1 | 18.8 | 5 | 14 | 30.6 | SMA |
| P4SMA24A | |
21.6 | 26.4 | 1 | 19.4 | 5 | 12 | 34.7 | SMA |
| P4SMA24CA | |
22.8 | 25.2 | 1 | 20.5 | 5 | 13 | 33.2 | SMA |
| P4SMA27A | |
24.3 | 29.7 | 1 | 21.8 | 5 | 11 | 39.1 | SMA |
| P4SMA27CA | |
25.7 | 28.4 | 1 | 23.1 | 5 | 11.2 | 37.5 | SMA |
| P4SMA30A | |
27 | 33 | 1 | 24.3 | 5 | 10 | 43.5 | SMA |
| P4SMA30CA | |
28.5 | 31.5 | 1 | 25.6 | 5 | 10 | 41.4 | SMA |
| P4SMA33A | |
29.7 | 36.3 | 1 | 26.8 | 5 | 9 | 47.7 | SMA |
| P4SMA33CA | |
31.4 | 34.7 | 1 | 28.2 | 5 | 9 | 45.7 | SMA |
| P4SMA36A | |
32.4 | 39.6 | 1 | 29.1 | 5 | 8 | 52 | SMA |
| P4SMA36CA | |
34.2 | 37.8 | 1 | 30.8 | 5 | 8.4 | 49.9 | SMA |
| P4SMA39A | |
35.1 | 42.9 | 1 | 31.6 | 5 | 7.4 | 56.4 | SMA |
| P4SMA39CA | |
37.1 | 41 | 1 | 33.3 | 5 | 7.8 | 53.9 | SMA |
| P4SMA43A | |
38.7 | 47.3 | 1 | 34.8 | 5 | 6.8 | 61.9 | SMA |
| P4SMA43CA | |
40.9 | 45.2 | 1 | 36.8 | 5 | 7.1 | 59.3 | SMA |
| P4SMA47A | |
42.3 | 51.7 | 1 | 38.1 | 5 | 6.2 | 67.8 | SMA |
| P4SMA47CA | |
44.7 | 49.4 | 1 | 40.2 | 5 | 5 | 64.8 | SMA |
| P4SMA51A | |
45.9 | 56.1 | 1 | 41.3 | 5 | 5.7 | 73.5 | SMA |
| P4SMA51CA | |
48.5 | 53.6 | 1 | 43.6 | 5 | 6 | 70.1 | SMA |
| P4SMA56A | |
50.4 | 61.6 | 1 | 45.6 | 5 | 5.2 | 80.5 | SMA |
| P4SMA56CA | |
53.2 | 58.8 | 1 | 47.8 | 5 | 5.5 | 77 | SMA |
| P4SMA62A | |
55.8 | 68.2 | 1 | 50.2 | 5 | 4.7 | 89 | SMA |
| P4SMA62CA | |
58.9 | 65.1 | 1 | 53 | 5 | 5 | 85 | SMA |
| P4SMA68A | |
61.2 | 74.8 | 1 | 55.1 | 5 | 4.3 | 98 | SMA |
| P4SMA68CA | |
64.6 | 71.4 | 1 | 58.1 | 5 | 4.6 | 92 | SMA |
| P4SMA75A | |
67.5 | 82.5 | 1 | 60.7 | 5 | 3.9 | 108 | SMA |
| P4SMA75CA | |
71.3 | 78.8 | 1 | 64.1 | 5 | 4.1 | 103 | SMA |
| P4SMA82A | |
73.8 | 90.2 | 1 | 66.4 | 5 | 3.6 | 118 | SMA |
| P4SMA82CA | |
77.9 | 86.1 | 1 | 70.1 | 5 | 3.7 | 113 | SMA |
| P4SMA91A | |
81.9 | 100 | 1 | 73.7 | 5 | 3.2 | 131 | SMA |
| P4SMA91CA | |
86.5 | 95.5 | 1 | 77.8 | 5 | 3.4 | 125 | SMA |
| P4SMA100A | |
90 | 110 | 1 | 81 | 5 | 2.9 | 144 | SMA |
| P4SMA100CA | |
95 | 105 | 1 | 85.5 | 5 | 3.1 | 137 | SMA |
| P4SMA110A | |
99 | 121 | 1 | 89.2 | 5 | 2.7 | 158 | SMA |
| P4SMA110CA | |
105 | 116 | 1 | 94 | 5 | 2.8 | 152 | SMA |
| P4SMA120A | |
108 | 132 | 1 | 97.2 | 5 | 2.4 | 173 | SMA |
| P4SMA120CA | |
114 | 126 | 1 | 102 | 5 | 2.5 | 165 | SMA |
| P4SMA130A | |
117 | 143 | 1 | 105 | 5 | 2.2 | 187 | SMA |
| P4SMA130CA | |
124 | 137 | 1 | 111 | 5 | 2.3 | 179 | SMA |
| P4SMA150A | |
135 | 165 | 1 | 121 | 5 | 2 | 215 | SMA |
| P4SMA150CA | |
143 | 158 | 1 | 128 | 5 | 2 | 207 | SMA |
| P4SMA160A | |
144 | 176 | 1 | 130 | 5 | 1.8 | 230 | SMA |
| P4SMA160CA | |
152 | 168 | 1 | 136 | 5 | 1.9 | 219 | SMA |
| P4SMA170A | |
153 | 187 | 1 | 138 | 5 | 1.7 | 244 | SMA |
| P4SMA170CA | |
162 | 179 | 1 | 145 | 5 | 1.8 | 234 | SMA |
| P4SMA180A | |
162 | 198 | 1 | 146 | 5 | 1.6 | 258 | SMA |
| P4SMA180CA | |
171 | 189 | 1 | 154 | 5 | 1.7 | 246 | SMA |
| P4SMA200A | |
180 | 220 | 1 | 162 | 5 | 1.5 | 287 | SMA |
| P4SMA200CA | |
190 | 210 | 1 | 171 | 5 | 1.5 | 274 | SMA |
| P4SMA220A | |
198 | 242 | 1 | 175 | 5 | 1.2 | 344 | SMA |
| P4SMA220CA | |
209 | 231 | 1 | 185 | 5 | 1.2 | 328 | SMA |
| P4SMA250A | |
225 | 275 | 1 | 202 | 5 | 1.1 | 360 | SMA |
| P4SMA250CA | |
237 | 263 | 1 | 214 | 5 | 1.2 | 344 | SMA |
| P6KE6.8CA | |
6.12 | 7.48 | 10 | 5.50 | 1000 | 55.6 | 10.8 | DO-15 |
| P6KE6.8A | |
6.45 | 7.14 | 10 | 5.80 | 1000 | 57.1 | 10.5 | DO-15 |
| P6KE7.5CA | |
6.75 | 8.25 | 10 | 6.05 | 500 | 51.3 | 11.7 | DO-15 |
| P6KE7.5A | |
7.13 | 7.88 | 10 | 6.40 | 500 | 53.1 | 11.3 | DO-15 |
| P6KE8.2CA | |
7.38 | 9.02 | 10 | 6.63 | 200 | 48.0 | 12.5 | DO-15 |
| P6KE8.2A | |
7.79 | 8.61 | 10 | 7.02 | 200 | 49.6 | 12.1 | DO-15 |
| P6KE9.1CA | |
8.19 | 10.0 | 1 | 7.37 | 50 | 43.5 | 13.8 | DO-15 |
| P6KE9.1A | |
8.65 | 9.55 | 1 | 7.78 | 50 | 44.8 | 13.4 | DO-15 |
| P6KE10CA | |
9.00 | 11.0 | 1 | 8.10 | 10 | 40.0 | 15.0 | DO-15 |
| P6KE10A | |
9.50 | 10.5 | 1 | 8.55 | 10 | 41.4 | 14.5 | DO-15 |
| P6KE11CA | |
9.90 | 12.1 | 1 | 8.92 | 5 | 37.0 | 16.2 | DO-15 |
| P6KE11A | |
10.5 | 11.6 | 1 | 9.40 | 5 | 38.5 | 15.6 | DO-15 |
| P6KE12CA | |
10.8 | 13.2 | 1 | 9.72 | 5 | 34.7 | 17.3 | DO-15 |
| P6KE12A | |
11.4 | 12.6 | 1 | 10.2 | 5 | 35.9 | 16.7 | DO-15 |
| P6KE13CA | |
11.7 | 14.3 | 1 | 10.5 | 5 | 31.6 | 19.0 | DO-15 |
| P6KE13A | |
12.4 | 13.7 | 1 | 11.1 | 5 | 33.0 | 18.2 | DO-15 |
| P6KE15CA | |
13.5 | 16.5 | 1 | 12.1 | 1 | 27.3 | 22.0 | DO-15 |
| P6KE15A | |
14.3 | 15.8 | 1 | 12.8 | 1 | 28.3 | 21.2 | DO-15 |
| P6KE16CA | |
14.4 | 17.6 | 1 | 12.9 | 1 | 25.5 | 23.5 | DO-15 |
| P6KE16A | |
15.2 | 16.8 | 1 | 13.6 | 1 | 26.7 | 22.5 | DO-15 |
| P6KE18CA | |
16.2 | 19.8 | 1 | 14.5 | 1 | 22.6 | 26.5 | DO-15 |
| P6KE18A | |
17.1 | 18.9 | 1 | 15.3 | 1 | 23.8 | 25.2 | DO-15 |
| P6KE20CA | |
18.0 | 22.0 | 1 | 16.2 | 1 | 20.6 | 29.1 | DO-15 |
| P6KE20A | |
19.0 | 21.0 | 1 | 17.1 | 1 | 21.7 | 27.7 | DO-15 |
| P6KE22CA | |
19.8 | 24.2 | 1 | 17.8 | 1 | 18.8 | 31.9 | DO-15 |
| P6KE22A | |
20.9 | 23.1 | 1 | 18.8 | 1 | 19.6 | 30.6 | DO-15 |
| P6KE24CA | |
21.6 | 26.4 | 1 | 19.4 | 1 | 17.3 | 34.7 | DO-15 |
| P6KE24A | |
22.8 | 25.2 | 1 | 20.5 | 1 | 18.1 | 33.2 | DO-15 |
| P6KE27CA | |
24.3 | 29.7 | 1 | 21.8 | 1 | 15.3 | 39.1 | DO-15 |
| P6KE27A | |
25.7 | 28.4 | 1 | 23.1 | 1 | 16.0 | 37.5 | DO-15 |
| P6KE30CA | |
27.0 | 33.0 | 1 | 24.3 | 1 | 13.8 | 43.5 | DO-15 |
| P6KE30A | |
28.5 | 31.5 | 1 | 25.6 | 1 | 14.5 | 41.4 | DO-15 |
| P6KE33CA | |
29.7 | 36.3 | 1 | 26.8 | 1 | 12.6 | 47.7 | DO-15 |
| P6KE33A | |
31.4 | 34.7 | 1 | 28.2 | 1 | 13.1 | 45.7 | DO-15 |
| P6KE36CA | |
32.4 | 39.6 | 1 | 29.1 | 1 | 11.5 | 52.0 | DO-15 |
| P6KE36A | |
34.2 | 37.8 | 1 | 30.8 | 1 | 12.0 | 49.9 | DO-15 |
| P6KE39CA | |
35.1 | 42.9 | 1 | 31.6 | 1 | 10.6 | 56.4 | DO-15 |
| P6KE39A | |
37.1 | 41.0 | 1 | 33.3 | 1 | 11.1 | 53.9 | DO-15 |
| P6KE43CA | |
38.7 | 47.3 | 1 | 34.8 | 1 | 9.7 | 61.9 | DO-15 |
| P6KE43A | |
40.9 | 45.2 | 1 | 36.8 | 1 | 10.1 | 59.3 | DO-15 |
| P6KE47CA | |
42.3 | 51.7 | 1 | 38.1 | 1 | 8.8 | 67.8 | DO-15 |
| P6KE47A | |
44.7 | 49.4 | 1 | 40.2 | 1 | 9.3 | 64.8 | DO-15 |
| P6KE51CA | |
45.9 | 56.1 | 1 | 41.3 | 1 | 8.2 | 73.5 | DO-15 |
| P6KE51A | |
48.5 | 53.6 | 1 | 43.6 | 1 | 8.6 | 70.1 | DO-15 |
| P6KE56CA | |
50.4 | 61.6 | 1 | 45.4 | 1 | 7.5 | 80.5 | DO-15 |
| P6KE56A | |
53.2 | 58.8 | 1 | 47.8 | 1 | 7.8 | 77.0 | DO-15 |
| P6KE62CA | |
55.8 | 68.2 | 1 | 50.2 | 1 | 6.7 | 89.0 | DO-15 |
| P6KE62A | |
58.9 | 65.1 | 1 | 53.0 | 1 | 7.1 | 85.0 | DO-15 |
| P6KE68CA | |
61.2 | 74.8 | 1 | 55.1 | 1 | 6.1 | 98.0 | DO-15 |
| P6KE68A | |
64.6 | 71.4 | 1 | 58.1 | 1 | 6.5 | 92.0 | DO-15 |
| P6KE75CA | |
67.5 | 82.5 | 1 | 60.7 | 1 | 5.6 | 108 | DO-15 |
| P6KE75A | |
71.3 | 78.8 | 1 | 64.1 | 1 | 5.8 | 103 | DO-15 |
| P6KE82CA | |
73.8 | 90.2 | 1 | 66.4 | 1 | 5.1 | 118 | DO-15 |
| P6KE82A | |
77.9 | 86.1 | 1 | 70.1 | 1 | 5.3 | 113 | DO-15 |
| P6KE91CA | |
81.9 | 100 | 1 | 73.7 | 1 | 4.6 | 131 | DO-15 |
| P6KE91A | |
86.5 | 95.5 | 1 | 77.8 | 1 | 4.8 | 125 | DO-15 |
| P6KE100CA | |
90.0 | 110 | 1 | 81.0 | 1 | 4.2 | 144 | DO-15 |
| P6KE100A | |
95.0 | 105 | 1 | 85.5 | 1 | 4.4 | 137 | DO-15 |
| P6KE110CA | |
99.0 | 121 | 1 | 89.2 | 1 | 3.8 | 158 | DO-15 |
| P6KE110A | |
105 | 116 | 1 | 94.0 | 1 | 3.9 | 152 | DO-15 |
| P6KE120CA | |
108 | 132 | 1 | 97.2 | 1 | 3.5 | 173 | DO-15 |
| P6KE120A | |
114 | 126 | 1 | 102 | 1 | 3.6 | 165 | DO-15 |
| P6KE130CA | |
117 | 143 | 1 | 105 | 1 | 3.2 | 187 | DO-15 |
| P6KE130A | |
124 | 137 | 1 | 111 | 1 | 3.4 | 179 | DO-15 |
| P6KE150CA | |
135 | 165 | 1 | 121 | 1 | 2.8 | 215 | DO-15 |
| P6KE150A | |
143 | 158 | 1 | 128 | 1 | 2.9 | 207 | DO-15 |
| P6KE160CA | |
144 | 176 | 1 | 130 | 1 | 2.6 | 230 | DO-15 |
| P6KE160A | |
152 | 168 | 1 | 136 | 1 | 2.7 | 219 | DO-15 |
| P6KE170CA | |
153 | 187 | 1 | 138 | 1 | 2.5 | 244 | DO-15 |
| P6KE170A | |
162 | 179 | 1 | 145 | 1 | 2.6 | 234 | DO-15 |
| P6KE180CA | |
162 | 198 | 1 | 146 | 1 | 2.3 | 258 | DO-15 |
| P6KE180A | |
171 | 189 | 1 | 154 | 1 | 2.4 | 246 | DO-15 |
| P6KE200CA | |
180 | 220 | 1 | 162 | 1 | 2.1 | 287 | DO-15 |
| P6KE200A | |
190 | 210 | 1 | 171 | 1 | 2.2 | 274 | DO-15 |
| P6KE220CA | |
198 | 242 | 1 | 175 | 1 | 1.7 | 344 | DO-15 |
| P6KE220A | |
209 | 231 | 1 | 185 | 1 | 1.8 | 328 | DO-15 |
| P6KE250CA | |
225 | 275 | 1 | 202 | 1 | 1.7 | 360 | DO-15 |
| P6KE250A | |
237 | 263 | 1 | 214 | 1 | 1.7 | 344 | DO-15 |
| P6KE300CA | |
270 | 330 | 1 | 243 | 1 | 1.4 | 430 | DO-15 |
| P6KE300A | |
285 | 315 | 1 | 256 | 1 | 1.4 | 414 | DO-15 |
| P6KE350CA | |
315 | 385 | 1 | 284 | 1 | 1.2 | 504 | DO-15 |
| P6KE350A | |
333 | 368 | 1 | 300 | 1 | 1.2 | 482 | DO-15 |
| P6KE400CA | |
360 | 440 | 1 | 324 | 1 | 1.0 | 574 | DO-15 |
| P6KE400A | |
380 | 420 | 1 | 342 | 1 | 1.1 | 548 | DO-15 |
| P6KE440CA | |
396 | 484 | 1 | 356 | 1 | 0.95 | 631 | DO-15 |
| P6KE440A | |
418 | 462 | 1 | 376 | 1 | 1.00 | 602 | DO-15 |
| P6KE480CA | |
432 | 528 | 1 | 389 | 1 | 0.88 | 686 | DO-15 |
| P6KE480A | |
456 | 504 | 1 | 408 | 1 | 0.91 | 658 | DO-15 |
| P6KE510CA | |
459 | 561 | 1 | 413 | 1 | 0.82 | 729 | DO-15 |
| P6KE510A | |
485 | 535 | 1 | 434 | 1 | 0.86 | 698 | DO-15 |
| P6KE540CA | |
486 | 594 | 1 | 437 | 1 | 0.78 | 772 | DO-15 |
| P6KE540A | |
513 | 567 | 1 | 459 | 1 | 0.81 | 740 | DO-15 |
| 1.5KE6.8CA | |
6.12 | 7.48 | 10 | 5.50 | 1000 | 139 | 10.8 | DO-27 |
| 1.5KE6.8A | |
6.45 | 7.14 | 10 | 5.80 | 1000 | 143 | 10.5 | DO-27 |
| 1.5KE7.5CA | |
6.75 | 8.25 | 10 | 6.05 | 500 | 128 | 11.7 | DO-27 |
| 1.5KE7.5A | |
7.13 | 7.88 | 10 | 6.40 | 500 | 133 | 11.3 | DO-27 |
| 1.5KE8.2CA | |
7.38 | 9.02 | 10 | 6.63 | 200 | 120 | 12.5 | DO-27 |
| 1.5KE8.2A | |
7.79 | 8.61 | 10 | 7.02 | 200 | 124 | 12.1 | DO-27 |
| 1.5KE9.1CA | |
8.19 | 10.0 | 1 | 7.37 | 50 | 109 | 13.8 | DO-27 |
| 1.5KE9.1A | |
8.65 | 9.55 | 1 | 7.78 | 50 | 112 | 13.4 | DO-27 |
| 1.5KE10CA | |
9.00 | 11.0 | 1 | 8.10 | 10 | 100 | 15.0 | DO-27 |
| 1.5KE10A | |
9.50 | 10.5 | 1 | 8.55 | 10 | 103 | 14.5 | DO-27 |
| 1.5KE11CA | |
9.90 | 12.1 | 1 | 8.92 | 5 | 92.6 | 16.2 | DO-27 |
| 1.5KE11A | |
10.5 | 11.6 | 1 | 9.40 | 5 | 96.2 | 15.6 | DO-27 |
| 1.5KE12CA | |
10.8 | 13.2 | 1 | 9.72 | 5 | 86.7 | 17.3 | DO-27 |
| 1.5KE12A | |
11.4 | 12.6 | 1 | 10.2 | 5 | 89.8 | 16.7 | DO-27 |
| 1.5KE13CA | |
11.7 | 14.3 | 1 | 10.5 | 5 | 78.9 | 19.0 | DO-27 |
| 1.5KE13A | |
12.4 | 13.7 | 1 | 11.1 | 5 | 82.4 | 18.2 | DO-27 |
| 1.5KE15CA | |
13.5 | 16.5 | 1 | 12.1 | 1 | 68.2 | 22.0 | DO-27 |
| 1.5KE15A | |
14.3 | 15.8 | 1 | 12.8 | 1 | 70.8 | 21.2 | DO-27 |
| 1.5KE16CA | |
14.4 | 17.6 | 1 | 12.9 | 1 | 63.8 | 23.5 | DO-27 |
| 1.5KE16A | |
15.2 | 16.8 | 1 | 13.6 | 1 | 66.7 | 22.5 | DO-27 |
| 1.5KE18CA | |
16.2 | 19.8 | 1 | 14.5 | 1 | 56.6 | 26.5 | DO-27 |
| 1.5KE18A | |
17.1 | 18.9 | 1 | 15.3 | 1 | 59.5 | 25.2 | DO-27 |
| 1.5KE20CA | |
18.0 | 22.0 | 1 | 16.2 | 1 | 51.5 | 29.1 | DO-27 |
| 1.5KE20A | |
19.0 | 21.0 | 1 | 17.1 | 1 | 54.2 | 27.7 | DO-27 |
| 1.5KE22CA | |
19.8 | 24.2 | 1 | 17.8 | 1 | 47.0 | 31.9 | DO-27 |
| 1.5KE22A | |
20.9 | 23.1 | 1 | 18.8 | 1 | 49.0 | 30.6 | DO-27 |
| 1.5KE24CA | |
21.6 | 26.4 | 1 | 19.4 | 1 | 43.2 | 34.7 | DO-27 |
| 1.5KE24A | |
22.8 | 25.2 | 1 | 20.5 | 1 | 45.2 | 33.2 | DO-27 |
| 1.5KE27CA | |
24.3 | 29.7 | 1 | 21.8 | 1 | 38.4 | 39.1 | DO-27 |
| 1.5KE27A | |
25.7 | 28.4 | 1 | 23.1 | 1 | 40.0 | 37.5 | DO-27 |
| 1.5KE30CA | |
27.0 | 33.0 | 1 | 24.3 | 1 | 34.5 | 43.5 | DO-27 |
| 1.5KE30A | |
28.5 | 31.5 | 1 | 25.6 | 1 | 36.2 | 41.4 | DO-27 |
| 1.5KE33CA | |
29.7 | 36.3 | 1 | 26.8 | 1 | 31.4 | 47.7 | DO-27 |
| 1.5KE33A | |
31.4 | 34.7 | 1 | 28.2 | 1 | 32.8 | 45.7 | DO-27 |
| 1.5KE36CA | |
32.4 | 39.6 | 1 | 29.1 | 1 | 28.8 | 52.0 | DO-27 |
| 1.5KE36A | |
34.2 | 37.8 | 1 | 30.8 | 1 | 30.1 | 49.9 | DO-27 |
| 1.5KE39CA | |
35.1 | 42.9 | 1 | 31.6 | 1 | 26.6 | 56.4 | DO-27 |
| 1.5KE39A | |
37.1 | 41.0 | 1 | 33.3 | 1 | 27.8 | 53.9 | DO-27 |
| 1.5KE43CA | |
38.7 | 47.3 | 1 | 34.8 | 1 | 24.2 | 61.9 | DO-27 |
| 1.5KE43A | |
40.9 | 45.2 | 1 | 36.8 | 1 | 25.3 | 59.3 | DO-27 |
| 1.5KE47CA | |
42.3 | 51.7 | 1 | 38.1 | 1 | 22.1 | 67.8 | DO-27 |
| 1.5KE47A | |
44.7 | 49.4 | 1 | 40.2 | 1 | 23.1 | 64.8 | DO-27 |
| 1.5KE51CA | |
45.9 | 56.1 | 1 | 41.3 | 1 | 20.4 | 73.5 | DO-27 |
| 1.5KE51A | |
48.5 | 53.6 | 1 | 43.6 | 1 | 21.4 | 70.1 | DO-27 |
| 1.5KE56CA | |
50.4 | 61.8 | 1 | 45.4 | 1 | 18.6 | 80.5 | DO-27 |
| 1.5KE56A | |
53.2 | 58.8 | 1 | 47.8 | 1 | 19.5 | 77.0 | DO-27 |
| 1.5KE62CA | |
55.8 | 68.2 | 1 | 50.2 | 1 | 16.9 | 89.0 | DO-27 |
| 1.5KE62A | |
58.9 | 65.1 | 1 | 53.0 | 1 | 17.6 | 85.0 | DO-27 |
| 1.5KE68CA | |
61.2 | 74.8 | 1 | 55.1 | 1 | 15.3 | 98.0 | DO-27 |
| 1.5KE68A | |
64.6 | 71.4 | 1 | 58.1 | 1 | 16.3 | 92.0 | DO-27 |
| 1.5KE75CA | |
67.5 | 82.5 | 1 | 60.7 | 1 | 13.9 | 109 | DO-27 |
| 1.5KE75A | |
71.3 | 78.8 | 1 | 64.1 | 1 | 14.6 | 104 | DO-27 |
| 1.5KE82CA | |
73.8 | 90.2 | 1 | 66.4 | 1 | 12.7 | 118 | DO-27 |
| 1.5KE82A | |
77.9 | 86.1 | 1 | 70.1 | 1 | 13.3 | 113 | DO-27 |
| 1.5KE91CA | |
81.9 | 100 | 1 | 73.7 | 1 | 11.5 | 131 | DO-27 |
| 1.5KE91A | |
86.5 | 95.5 | 1 | 77.8 | 1 | 12.0 | 125 | DO-27 |
| 1.5KE100CA | |
90.0 | 110 | 1 | 81.0 | 1 | 10.4 | 144 | DO-27 |
| 1.5KE100A | |
95.0 | 105 | 1 | 85.5 | 1 | 10.9 | 137 | DO-27 |
| 1.5KE110CA | |
99.0 | 121 | 1 | 89.2 | 1 | 9.5 | 158 | DO-27 |
| 1.5KE110A | |
105 | 116 | 1 | 94.0 | 1 | 9.9 | 152 | DO-27 |
| 1.5KE120CA | |
108 | 132 | 1 | 97.2 | 1 | 8.7 | 173 | DO-27 |
| 1.5KE120A | |
114 | 126 | 1 | 102 | 1 | 9.1 | 165 | DO-27 |
| 1.5KE130CA | |
117 | 143 | 1 | 105 | 1 | 8.0 | 187 | DO-27 |
| 1.5KE130A | |
124 | 137 | 1 | 111 | 1 | 8.4 | 179 | DO-27 |
| 1.5KE150CA | |
135 | 165 | 1 | 121 | 1 | 7.0 | 215 | DO-27 |
| 1.5KE150A | |
143 | 158 | 1 | 128 | 1 | 7.2 | 207 | DO-27 |
| 1.5KE160CA | |
144 | 176 | 1 | 130 | 1 | 6.5 | 230 | DO-27 |
| 1.5KE160A | |
152 | 168 | 1 | 136 | 1 | 6.8 | 219 | DO-27 |
| 1.5KE170CA | |
153 | 187 | 1 | 138 | 1 | 6.1 | 244 | DO-27 |
| 1.5KE170A | |
162 | 179 | 1 | 145 | 1 | 6.4 | 234 | DO-27 |
| 1.5KE180CA | |
162 | 198 | 1 | 146 | 1 | 5.8 | 258 | DO-27 |
| 1.5KE180A | |
171 | 189 | 1 | 154 | 1 | 6.1 | 246 | DO-27 |
| 1.5KE200CA | |
180 | 220 | 1 | 162 | 1 | 5.2 | 287 | DO-27 |
| 1.5KE200A | |
190 | 210 | 1 | 171 | 1 | 5.5 | 274 | DO-27 |
| 1.5KE220CA | |
198 | 242 | 1 | 175 | 1 | 4.4 | 344 | DO-27 |
| 1.5KE220A | |
209 | 231 | 1 | 185 | 1 | 4.6 | 328 | DO-27 |
| 1.5KE250CA | |
225 | 275 | 1 | 202 | 1 | 4.2 | 360 | DO-27 |
| 1.5KE250A | |
237 | 263 | 1 | 214 | 1 | 4.4 | 344 | DO-27 |
| 1.5KE300CA | |
270 | 330 | 1 | 243 | 1 | 3.5 | 430 | DO-27 |
| 1.5KE300A | |
285 | 315 | 1 | 256 | 1 | 3.6 | 414 | DO-27 |
| 1.5KE350CA | |
315 | 385 | 1 | 284 | 1 | 3.0 | 504 | DO-27 |
| 1.5KE350A | |
333 | 368 | 1 | 300 | 1 | 3.1 | 482 | DO-27 |
| 1.5KE400CA | |
360 | 440 | 1 | 324 | 1 | 2.6 | 574 | DO-27 |
| 1.5KE400A | |
380 | 420 | 1 | 342 | 1 | 2.7 | 548 | DO-27 |
| 1.5KE440CA | |
396 | 484 | 1 | 356 | 1 | 2.4 | 631 | DO-27 |
| 1.5KE440A | |
418 | 462 | 1 | 376 | 1 | 2.5 | 602 | DO-27 |
| 1.5KE480CA | |
432 | 528 | 1 | 389 | 1 | 2.19 | 686 | DO-27 |
| 1.5KE480A | |
456 | 504 | 1 | 408 | 1 | 2.28 | 658 | DO-27 |
| 1.5KE510CA | |
459 | 561 | 1 | 413 | 1 | 2.06 | 729 | DO-27 |
| 1.5KE510A | |
485 | 535 | 1 | 434 | 1 | 2.15 | 698 | DO-27 |
| 1.5KE540CA | |
486 | 594 | 1 | 437 | 1 | 1.94 | 772 | DO-27 |
| 1.5KE540A | |
513 | 567 | 1 | 459 | 1 | 2.03 | 740 | DO-27 |
推荐产品
/Recommended products
-
SMBJ48A瞬态抑制二极管-SMBJ48A单向TVS管
查看详细 立即咨询 -
SMBJ45A瞬态抑制二极管-SMBJ45A单向TVS管
查看详细 立即咨询 -
SMBJ43A瞬态抑制二极管-SMBJ43A单向TVS管
查看详细 立即咨询 -
SMBJ40A瞬态抑制二极管-SMBJ40A单向TVS管
查看详细 立即咨询 -
SMBJ36A瞬态抑制二极管-SMBJ36A单向TVS管
查看详细 立即咨询 -
SMBJ33A瞬态抑制二极管-SMBJ33A单向TVS管
查看详细 立即咨询
1
